Totolink N9 Access Point 300Mb/s, 2,4GHz, PoE, 1x RJ45 100Mb/s, 2x dBi

Features / filters
LAN standard Fast Ethernet 10/100Mb/s
Number of LAN ports 1x 10/100BaseTX (RJ45)
Number of WAN ports Not applicable
Operating frequency 2.4 GHz
Wireless network standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b,
Built-in modem None
Device type Access point
Type of device power supply PoE 802.3af/at
Basic technical parameters
Interface 1 *100BaseTX (Auto MDI/MDIX) LAN port
Button 1 *Reset/WPS
Power supply 48V DC/0.6A
IEEE 802.11af PoE
LED indicator 1 *System
Antenna 2 *4dBi internal antennae
Environment Operating temperature range: 0℃~55℃ (32℉~131℉)
Storage temperature: -20~65℃ (-4℉~149℉)
Moisture range: 10%~90% non-condensing
Storage temperature: 5%~95% non-condensing
Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u, IEEE 802.3af
RF frequency 2.4~2.4835 GHz
Data transfer rate 802. 11n: up to 300Mbps
802.11g: up to 54Mbps (dynamic)
802.11b: up to 11Mbps (dynamic)
Wireless network protection 64/128-bit WEP, WPA/WPA2, WPA - PSK/WPA2-PSK (TKIP/AES)
EIRP <20dBm
Channels 1-11 (North America), 1-13 (Europe), 1-14 (Japan)
Type of modulation DBPSK, DQPSK, CCK and OFDM (BPSK,QPSK,16-QAM/ 64-QAM)
Sensitivity of reception 270M: -61 dBm@10% PER
135M: -65 dBm@10% PER
54M: -68 dBm@10% PER
11M: -85 dBm@8% PER
6M: -88 dBm@10% PER
1M: -90 dBm@8% PER
Network LAN status
LAN/DHCP configuration
Wireless Wireless network status
Wireless configuration
Many BSSs
Wireless Multibridge
MAC Authentication
WDS, WPS
Advanced settings
System System logs
Administrator configuration
Software update
System time
Backup/restore configuration
Various settings
